LLF Series

LLF series coaxial cable is cost-effective low loss flexible cable. It is designed to be installed in narrow and small space. The center conductor is stranded silver-plated copper which makes LLF series more flexible. It can keep phase stable while bending. Meanwhile, LLF cables offer higher operating temperature range, lower loss and better RF shielding than traditional foam PE cables.

Product Structure
Center Conductor	Silver plated copper
Dielectric	LD PTFE
Outer Conductor	Aluminium Foil
Outer shield	Silver plated copper
Oute Jacket	Blue FEP

Features and Advantages

Low loss
Cost-effective
High temp range
Good flexibility

Typical Applications

GPS positioning
Cellular networks
Wireless communication

Product List

LLF-400 High Performance Microwave Coax Cable

Working frequency: 18 GHz
Cable outer diameter: 4.0mm
Temperature range: -55℃~85℃
LLF-600 High Performance Microwave Coax Cable

Working frequency: 13.5 GHz
Cable outer diameter: 6.0mm
Temperature range: -55℃~85℃
LLF-820 High Performance Microwave Coax Cable

Working frequency: 13.5 GHz
Cable outer diameter: 8.2mm
Temperature range: -55℃~85℃
