Application
- The network system.
- Meter and instrument.
- Radio broadcasting.
- Nation defence or aerospace applications.
| Electrical Performance | |
|---|---|
| Impedance | 50 Ohm |
| Frequency range | DC-2.5 GHz |
| Voltage Rating | 830 V(RMS) |
| Dielectric Withstanding Voltage | 2500 V(RMS) |
| Conductor resistance | Inner conductor: ≤5.0 mΩ (initial value) |
| Outer conductor: ≤3.0 mΩ (initial value) | |
| Insulation resistance | ≥5000 mΩ |
| VSWR | Straight: ≤1.30 (typical value) |
| Right angle:: ≤1.35 (typical value) | |
| Mechanical Characteristics | |
|---|---|
| Nut pull force | ≥80 lbs |
| Nut torque | ≥15 inch.·lbs |
| Center pin retention | ≥6 lbs |
| Durability | >500Cycles |
