Application
- Telecommunications and military aviation.
- Missile, defense or aerospace applications.
| Electrical Performance | |
|---|---|
| Characteristic impedance | 50 Ohm |
| Frequency range | DC-34 GHz |
| Voltage Rating | 250 V(rms) |
| Dielectric Withstanding Voltage | 750 V(rms) |
| Conductor resistance | Inner conductor: ≤4.0 mΩ (initial value) |
| Outer conductor: ≤2.5 mΩ (initial value) | |
| Insulation resistance | ≥5000 mΩ |
| VSWR | Straight type: ≤1.30 (typical value) |
| Curved type: ≤1.35 (typical value) | |
| Mechanical behavior | |
|---|---|
| Nut pull | ≥22.5 lbs |
| Thread torque | ≥10 in·lbs |
| Center pin retention | ≥6 lbs |
| Durability | >500Cycles |
