Products | M12 Series Connectors: Signal Interconnection Solutions for Harsh Industrial Environments
2025-02-28
SLK New Product Launch
In the demanding environment of industrial automation, stable and reliable connections are key to efficient equipment operation. SLK’s newly launched M12 series connectors, with our outstanding performance and wide applicability, provide smarter and more durable solutions for customers worldwide.
Applications
SLK M12 connectors have been successfully applied across various industries worldwide:
▶ Industrial Automation: Sensors (pressure, temperature, load), solenoid valves, and PLC control systems.
▶ Heavy Machinery: Construction equipment, mining machinery, shipbuilding, and automotive manufacturing.
▶Energy & Power: Power equipment, substations, and new energy systems.
▶ Smart Manufacturing: Industrial Ethernet, robotics, hydraulic machine tools, and intelligent production lines.
Technical Specification
|
Number of stitches |
3，4，5，8，12，17 PIN |
|
Keypad |
A-CODE: for transmission of BCP56-16T1G sensor signals and power signals B-CODE: for field buses (e.g. Profibus) C-CODE: for alternating current signals D-CODE: for industrial device buses, e.g. CAN bus, DeviceNet, etc. X-CODE: for transmission of high-speed differential signals, capable of handling bandwidth requirements of up to 10 Gb/s for high-speed data transmission X-CODE: for high-speed differential signaling, can handle up to 10 Gb/s bandwidth requirements, suitable for high-speed data transmission. |
|
Locking method |
M12 threaded connection |
|
Applicable cable range |
26~24AWG |
|
Contact resistance |
<8mΩ |
|
Operating Temperature Range |
-25℃~+85℃ |
|
Operating/Pulse Voltage |
60V/1500V |
|
Rated current |
4A（Signal），12A（ Power） |
|
Protection class |
IP67/ IP68/IP 69K（Customized） |
|
Mechanical life |
>100次 |
