Application
- It is suitable for microwave transmission, mobile communication system and other applications
The LC series coaxial connector is a large 50Ω impedance threaded connector with large dimensions, high voltage, high shock resistance and excellent mechanical and electrical properties in accordance with US military standard MIL-STD-348.
It is designed to be compatible with .393" to 1.00" cable sizes as a coaxial connector for indoor and outdoor use for high energy transmission connections.
| Electrical Performance | |
|---|---|
| Characteristic impedance | 50 Ω |
| Frequency range | DC-1 GHz |
| Operating voltage | 3000 V(rms) |
| Dielectric withstanding voltage | 5000 V(rms) |
| Conductor resistance | inner conductor: ≤1.0 mΩ (initial value) |
| Outer conductor: ≤0.2 mΩ (initial value) | |
| Insulation resistance | ≥10 GΩ |
| VSWR | S Type: ≤1.30 (typical value) |
| R Type: ≤1.35 (typical value) | |
| Mechanical Characteristics | |
|---|---|
| Nut Pull | ≥225 lbs |
| Nut Torque | ≥100 inch.lbs |
| Center pin retention | ≥45 lbs |
| Durability | 500 cycles |
