Application
- It is suitable for environments with greater withstand voltage requirements and high-power environments .
- It can be used in place of some N-type connectors in high-voltage environments.
HN series connector is a medium-sized threaded RF coaxial connector.It adopts the insulator of Teflon material to realize the full package structure. They are typically below 4GHz with an impedance of 50 Ω.
It has the characteristics of good waterproof, strong shock resistance, high reliability and conforms to MIL-STD-348A standard. It is widely used in high-power working environment of base station devices, communication transmission system and medical devices.
| Electrical Performance | |
|---|---|
| Characteristic impedance | 50 Ω |
| Frequency range | DC-4 GHz |
| Operating voltage | 1330 V(rms) |
| Dielectric withstanding voltage | 4000 V(rms) |
| Conductor resistance | inner conductor: ≤1.0 mΩ (initial value) |
| Outer conductor: ≤0.2 mΩ (initial value) | |
| Insulation resistance | ≥5000 MΩ |
| VSWR | S Type: ≤1.30 (typical value) |
| R Type: ≤1.35 (typical value) | |
| Mechanical Characteristics | |
|---|---|
| Nut Pull | ≥100 lbs |
| Nut Torque | ≥15 inch.lbs |
| Center pin retention | ≥6 lbs |
| Durability | 500 cycles |
